2022 Yamaha Bolt R-Spec

2022 Yamaha Bolt R-Spec

BORN WITH PERFORMANCE

Featuring a torquey V-Twin engine, this performance bobber combines old-school soul and modern form.

Features may include:

• Urban Performance Styling

The Bolt R-Spec is stripped down with minimal chrome, epitomizing the “Urban Performance Bobber” look. The compact chassis proudly showcases the 58-cubic-inch (942cc) air-cooled 60-degree V-twin poweplant.

• Rider-Focused Engine

The Bolt R-Spec uses Yamaha’s advanced technology to create a riding experience superior to other similarly sized machines. Fuel injection and ignition timing maps have been chosen specifically for this bike to deliver class-leading performance with strong low- and mid-range torque that’s sure to bring a smile to every rider’s face.

ENGINE

• Air-Cooled V-Twin

The 58-cubic-inch (942cc) engine is an air-cooled SOHC 60-degree V-twin with four valves per cylinder, a pent-roof shaped combustion chamber and 9.0:1 compression ratio. The engine is designed to provide excellent power and superior low-end torque.

• Low Friction Internals

Special roller-type rocker arms with needle bearings are used to keep friction loss to a minimum, increase durability and help the engine achieve the ideal performance characteristics.

• Advanced Cylinder Design

The pent-roof combustion chamber shape was precisely engineered to direct the fuel/air charge to the center of the piston for more efficient combustion and maximum power. Ceramic-composite plated cylinders provide excellent heat dissipation and reduced oil consumption.

CHASSIS/SUSPENSION

• Handling-Focused Frame

A double-cradle frame provides precise handling and enhances city riding enjoyment thanks to the rigid mount system mounting the engine directly to the frame.

• Low Seat Height

The low-set seat provides a great riding position while being a mere 27.2 inches off the pavement, so most riders can easily put both feet firmly on the ground at a stop.

• Agile Wheelbase

Bolt R-Spec’s short, 61.8-inch wheelbase contributes to the bike’s great handling, providing precise, tight turns in city riding and solid, stable handling on the open road.

Specifications

• 2022 Yamaha Bolt R-Spec Base
• Year2022
• ManufacturerYamaha
• Model NameBolt R-Spec
• Trim NameBase
• Generic Type (Primary)Sport
• Engine TypeSOHC V-twin; 4 valves
• Displacement58-cubic-inch (942cc)
• Cooling SystemAir-cooled
• Bore85.0mm
• Stroke83.0mm
• Compression Ratio9.0:1
• Fuel SystemFuel injection
• IgnitionTCI: Transistor Controlled Ignition
• Fuel Economy: Combined City/Hwy51 mpg
• Drivetrain
• Transmission5-speed; multiplate wet clutch
• Final DriveBelt
• Suspension
• Front SuspensionTelescopic fork
• Front Travel (in./cm.)4.7-in
• Rear SuspensionDual piggyback shocks
• Rear Travel (in./cm.)2.8-in
• Brakes
• Front braking systemHydraulic single disc, 298mm
• Rear braking systemHydraulic single disc, 298mm
• Wheels & Tires
• Front Tire100/90-19 Bridgestone® EXEDRA G721 F
• Rear Tire150/80-16 Bridgestone® EXEDRA G722 R
• Dimensions
• Overall Vehicle Size (LxWxH)90.2 in x 37.2 in x 44.1 in
• Seat Height27.2 in
• Wheelbase61.8 in
• Rake/trail29.0°/5.1 in
• Ground Clearance5.1 in
• Capacities
• Fuel Capacity3.4 gal
• Weights
• WeightWet: 542 lb
• Color
• ColorsStorm Gray
